Software Reliability

Carnegie Mellon University

18-849b Dependable Embedded SystemsHREF="http://www.ece.cmu.edu/~ece849b">

Spring 1999

Authors: Jiantao Pan

jpan@cmu.edu

Abstract:

Software Reliability is the probability of failure-free software operation
for a specified period of time in a specified environment. Software Reliability
is also an important factor affecting system reliability. It differs from
hardware reliability in that it reflects the design perfection, rather than
manufacturing perfection. The high complexity of software is the major
contributing factor of Software Reliability problems. Software Reliability is
not a function of time - although researchers have come up with models relating
the two. The modeling technique for Software Reliability is reaching its
prosperity, but before using the technique, we must carefully select the
appropriate model that can best suit our case. Measurement in software is still
in its infancy. No good quantitative methods have been developed to represent
Software Reliability without excessive limitations. Various approaches can be
used to improve the reliability of software, however, it is hard to balance
development time and budget with software reliability.

Introduction: Embedded Software -- Embedded
Disasters?

With the advent of the computer age, computers, as well as the software
running on them, are playing a vital role in our daily lives. We may not have
noticed, but appliances such as washing machines, telephones, TVs, and watches,
are having their analog and mechanical parts replaced by CPUs and software. The
computer industry is booming exponentially. With a continuously lowering cost
and improved control, processors and software controlled systems offer compact
design, flexible handling, rich features and competitive cost. Like machinery
replaced craftsmanship in the industrial revolution, computers and intelligent
parts are quickly pushing their mechanical counterparts out of the market.

People used to believe that "software never breaks". Intuitively,
unlike mechanical parts such as bolts, levers, or electronic parts such as
transistors, capacitor, software will stay "as is" unless there are
problems in hardware that changes the storage content or data path. Software
does not age, rust, wear-out, deform or crack. There is no environmental
constraint for software to operate as long as the hardware processor it runs on
can operate. Furthermore, software has no shape, color, material, mass. It can
not be seen or touched, but it has a physical existence and is crucial to
system functionality.

Without being proven to be wrong, optimistic people would think that once
after the software can run correctly, it will be correct forever. A series of
tragedies and chaos caused by software proves this to be wrong. These events
will always have their place in history.

Tragedies in Therac 25 [Therac 25], a
computer-controlled radiation-therapy machine in the year 1986, caused by the
software not being able to detect a race condition, alerts us that it is
dangerous to abandon our old but well-understood mechanical safety control and
surrender our lives completely to software controlled safety mechanism.

Software can make decisions, but can just as unreliable as human beings. The
British destroyer Sheffield was sunk because the radar system identified an
incoming missile as "friendly". [Sheffield]
The defense system has matured to the point that it will not mistaken the
rising moon for incoming missiles, but gas-field fire, descending space junk,
etc, were also examples that can be misidentified as incoming missiles by the
defense system. [Neumann95]

Software can also have small unnoticeable errors or drifts that can
culminate into a disaster. On February 25, 1991, during the Golf War, the
chopping error that missed 0.000000095 second in precision in every 10th of a
second, accumulating for 100 hours, made the Patriot missile fail to intercept
a scud missile. 28 lives were lost. [Patriot]

Fixing problems may not necessarily make the software more reliable. On the
contrary, new serious problems may arise. In 1991, after changing three lines
of code in a signaling program which contains millions lines of code, the local
telephone systems in California and along the Eastern seaboard came to a stop.
[Telephone outage]

Once perfectly working software may also break if the running environment
changes. After the success of Ariane 4 rocket, the maiden flight of Ariane 5
ended up in flames while design defects in the control software were unveiled
by faster horizontal drifting speed of the new rocket. HREF="#reference">[Ariane 5]

There are much more scary stories to tell. This makes us wondering whether
software is reliable at all, whether we should use software in safety-critical
embedded applications. You can hardly ruin your clothes if the embedded
software in your washing machine issues erroneous commands; and 50% of the
chances you will be happy if the ATM machine miscalculates your money; but in
airplanes, heart pace-makers, radiation therapy machines, a software error can
easily claim people's lives. With processors and software permeating safety
critical embedded world, the reliability of software is simply a matter of life
and death. Are we embedding potential disasters while we embed software into
systems?

Key Concepts

Definition

According to ANSI, Software Reliability is defined as: the probability of
failure-free software operation for a specified period of time in a specified
environment. [ANSI91][Lyu95]Although Software
Reliability is defined as a probabilistic function, and comes with the notion
of time, we must note that, different from traditional Hardware Reliability,
Software Reliability is not a direct function of time. Electronic and
mechanical parts may become "old" and wear out with time and usage,
but software will not rust or wear-out during its life cycle. Software will not
change over time unless intentionally changed or upgraded.

Software Reliability is an important to attribute of software quality,
together with functionality, usability, performance, serviceability,
capability, installability, maintainability, and documentation. Software
Reliability is hard to achieve, because the complexity of software tends to be
high. While any system with a high degree of complexity, including software,
will be hard to reach a certain level of reliability, system developers tend to
push complexity into the software layer, with the rapid growth of system size
and ease of doing so by upgrading the software. For example, large
next-generation aircraft will have over one million source lines of software
on-board; next-generation air traffic control systems will contain between one
and two million lines; the upcoming international Space Station will have over
two million lines on-board and over ten million lines of ground support
software; several major life-critical defense systems will have over five
million source lines of software. [Rook90] While the
complexity of software is inversely related to software reliability, it is
directly related to other important factors in software quality, especially
functionality, capability, etc. Emphasizing these features will tend to add
more complexity to software.

Software failure mechanisms

Software failures may be due to errors, ambiguities, oversights or
misinterpretation of the specification that the software is supposed to
satisfy, carelessness or incompetence in writing code, inadequate testing,
incorrect or unexpected usage of the software or other unforeseen problems.HREF="#reference">[Keiller91] While it is tempting to draw an analogy
between Software Reliability and Hardware Reliability, software and hardware
have basic differences that make them different in failure mechanisms. Hardware
faults are mostly physical faults, while software faults are design
faults, which are harder to visualize, classify, detect, and correct.
[Lyu95] Design faults are closely related to fuzzy
human factors and the design process, which we don't have a solid
understanding. In hardware, design faults may also exist, but physical faults
usually dominate. In software, we can hardly find a strict corresponding
counterpart for "manufacturing" as hardware manufacturing process, if
the simple action of uploading software modules into place does not count.
Therefore, the quality of software will not change once it is uploaded into the
storage and start running. Trying to achieve higher reliability by simply
duplicating the same software modules will not work, because design faults can
not be masked off by voting.

A partial list of the distinct characteristics of software compared to
hardware is listed below [Keene94]:

Failure cause: Software defects are mainly design defects.

Wear-out: Software does not have energy related wear-out phase.
Errors can occur without warning.

Repairable system concept: Periodic restarts can help fix software
problems.

Time dependency and life cycle: Software reliability is not a
function of operational time.

Environmental factors: Do not affect Software reliability, except
it might affect program inputs.

Reliability prediction: Software reliability can not be predicted
from any physical basis, since it depends completely on human factors in
design.

Redundancy: Can not improve Software reliability if identical
software components are used.

Interfaces: Software interfaces are purely conceptual other than
visual.

Failure rate motivators: Usually not predictable from analyses of
separate statements.

Built with standard components: Well-understood and
extensively-tested standard parts will help improve maintainability and
reliability. But in software industry, we have not observed this trend. Code
reuse has been around for some time, but to a very limited extent. Strictly
speaking there are no standard parts for software, except some standardized
logic structures.

The bathtub curve for Software Reliability

Over time, hardware exhibits the failure characteristics shown in Figure 1,
known as the bathtub curve. Period A, B and C stands for burn-in phase, useful
life phase and end-of-life phase. A detailed discussion about the curve can be
found in the topic
HREF="/F:/usr/jpan/traditional_reliability/index.html#Component Reliability Lifetime Model">Traditional
Reliability.

Figure 1. Bathtub curve for hardware
reliability

Software reliability, however, does not show the same characteristics
similar as hardware. A possible curve is shown in Figure 2 if we projected
software reliability on the same axes. [RAC96] There
are two major differences between hardware and software curves. One difference
is that in the last phase, software does not have an increasing failure rate as
hardware does. In this phase, software is approaching obsolescence; there are
no motivation for any upgrades or changes to the software. Therefore, the
failure rate will not change. The second difference is that in the useful-life
phase, software will experience a drastic increase in failure rate each time an
upgrade is made. The failure rate levels off gradually, partly because of the
defects found and fixed after the upgrades.

Figure 2. Revised bathtub curve for software
reliability

The upgrades in Figure 2 imply feature upgrades, not upgrades for
reliability. For feature upgrades, the complexity of software is likely to be
increased, since the functionality of software is enhanced. Even bug fixes may
be a reason for more software failures, if the bug fix induces other defects
into software. For reliability upgrades, it is possible to incur a drop in
software failure rate, if the goal of the upgrade is enhancing software
reliability, such as a redesign or reimplementation of some modules using
better engineering approaches, such as clean-room method.

A proof can be found in the result from Ballista project, robustness testing
of off-the-shelf software Components. Figure 3 shows the testing results of
fifteen POSIX compliant operating systems. From the graph we see that for QNX
and HP-UX, robustness failure rate increases after the upgrade. But for SunOS,
IRIX and Digital UNIX, robustness failure rate drops when the version numbers
go up. Since software robustness is one aspect of software reliability, this
result indicates that the upgrade of those systems shown in Figure 3 should
have incorporated reliability upgrades.

Available tools, techniques, and metrics

Since Software Reliability is one of the most important aspects of software
quality, Reliability Engineering approaches are practiced in software field as
well. Software Reliability Engineering (SRE) is the quantitative study
of the operational behavior of software-based systems with respect to user
requirements concerning reliability [IEEE95].

Software Reliability
Models

A proliferation of software reliability models have emerged as people try to
understand the characteristics of how and why software fails, and try to
quantify software reliability. Over 200 models have been developed since the
early 1970s, but how to quantify software reliability still remains largely
unsolved. Interested readers may refer to [RAC96],
[Lyu95]. As many models as there are and many more
emerging, none of the models can capture a satisfying amount of the complexity
of software; constraints and assumptions have to be made for the quantifying
process. Therefore, there is no single model that can be used in all
situations. No model is complete or even representative. One model may work
well for a set of certain software, but may be completely off track for other
kinds of problems.

Most software models contain the following parts: assumptions,
factors, and a mathematical function that relates the reliability with the
factors. The mathematical function is usually higher order exponential or
logarithmic.

Software modeling techniques can be divided into two subcategories:
prediction modeling and estimation modeling. [RAC96]
Both kinds of modeling techniques are based on observing and accumulating
failure data and analyzing with statistical inference. The major difference of
the two models are shown in Table 1.

ISSUES	PREDICTION MODELS	ESTIMATION MODELS
DATA REFERENCE	Uses historical data	Uses data from the current software development effort
WHEN USED IN DEVELOPMENT CYCLE	Usually made prior to development or test phases; can be used as early as concept phase	Usually made later in life cycle(after some data have been collected); not typically used in concept or development phases
TIME FRAME	Predict reliability at some future time	Estimate reliability at either present or some future time

Table 1. Difference between software
reliability prediction models and software reliability estimation
models

Representative prediction models include Musa's Execution Time Model,
Putnam's Model. and Rome Laboratory models TR-92-51 and TR-92-15, etc. Using
prediction models, software reliability can be predicted early in the
development phase and enhancements can be initiated to improve the reliability.

Representative estimation models include exponential distribution models,
Weibull distribution model, Thompson and Chelson's model, etc. Exponential
models and Weibull distribution model are usually named as classical fault
count/fault rate estimation models, while Thompson and Chelson's model belong
to Bayesian fault rate estimation models.

The field has matured to the point that software models can be applied in
practical situations and give meaningful results and, second, that there is no
one model that is best in all situations. [Lyu95]
Because of the complexity of software, any model has to have extra assumptions.
Only limited factors can be put into consideration. Most software reliability
models ignore the software development process and focus on the results -- the
observed faults and/or failures. By doing so, complexity is reduced and
abstraction is achieved, however, the models tend to specialize to be applied
to only a portion of the situations and a certain class of the problems. We
have to carefully choose the right model that suits our specific case.
Furthermore, the modeling results can not be blindly believed and applied.

Software Reliability
Metrics

Measurement is commonplace in other engineering field, but not in software
engineering. Though frustrating, the quest of quantifying software reliability
has never ceased. Until now, we still have no good way of measuring software
reliability.

Measuring software reliability remains a difficult problem because we don't
have a good understanding of the nature of software. There is no clear
definition to what aspects are related to software reliability. We can not find
a suitable way to measure software reliability, and most of the aspects related
to software reliability. Even the most obvious product metrics such as software
size have not uniform definition.

It is tempting to measure something related to reliability to reflect the
characteristics, if we can not measure reliability directly. The current
practices of software reliability measurement can be divided into four
categories: [RAC96]

Product metrics

Software size is thought to be reflective of complexity, development effort
and reliability. Lines Of Code (LOC), or LOC in thousands(KLOC), is an
intuitive initial approach to measuring software size. But there is not a
standard way of counting. Typically, source code is used(SLOC, KSLOC) and
comments and other non-executable statements are not counted. This method can
not faithfully compare software not written in the same language. The advent of
new technologies of code reuse and code generation technique also cast doubt on
this simple method.

Function point metric is a method of measuring the functionality of a
proposed software development based upon a count of inputs, outputs, master
files, inquires, and interfaces. The method can be used to estimate the size of
a software system as soon as these functions can be identified. It is a measure
of the functional complexity of the program. It measures the functionality
delivered to the user and is independent of the programming language. It is
used primarily for business systems; it is not proven in scientific or
real-time applications.

Complexity is directly related to software reliability, so representing
complexity is important. Complexity-oriented metrics is a method of determining
the complexity of a program's control structure, by simplify the code into a
graphical representation. Representative metric is McCabe's Complexity Metric.

Test coverage metrics are a way of estimating fault and reliability by
performing tests on software products, based on the assumption that software
reliability is a function of the portion of software that has been successfully
verified or tested. Detailed discussion about various software testing methods
can be found in topic Software Testing.

Project management metrics

Researchers have realized that good management can result in better
products. Research has demonstrated that a relationship exists between the
development process and the ability to complete projects on time and within the
desired quality objectives. Costs increase when developers use inadequate
processes. Higher reliability can be achieved by using better development
process, risk management process, configuration management process, etc.

Process metrics

Based on the assumption that the quality of the product is a direct function
of the process, process metrics can be used to estimate, monitor and improve
the reliability and quality of software. ISO-9000 certification, or
"quality management standards", is the generic reference for a family
of standards developed by the International Standards Organization(ISO).

Fault and failure metrics

The goal of collecting fault and failure metrics is to be able to determine
when the software is approaching failure-free execution. Minimally, both the
number of faults found during testing (i.e., before delivery) and the failures
(or other problems) reported by users after delivery are collected, summarized
and analyzed to achieve this goal. Test strategy is highly relative to the
effectiveness of fault metrics, because if the testing scenario does not cover
the full functionality of the software, the software may pass all tests and yet
be prone to failure once delivered. Usually, failure metrics are based upon
customer information regarding failures found after release of the software.
The failure data collected is therefore used to calculate failure density, Mean
Time Between Failures (MTBF) or other parameters to measure or predict software
reliability.

Software Reliability Improvement
Techniques

Good engineering methods can largely improve software reliability.

Before the deployment of software products, testing, verification and
validation are necessary steps. Software testing is heavily used to trigger,
locate and remove software defects. Software testing is still in its infant
stage; testing is crafted to suit specific needs in various software
development projects in an ad-hoc manner. Various analysis tools such as trend
analysis, fault-tree analysis, Orthogonal Defect classification and formal
methods, etc, can also be used to minimize the possibility of defect occurrence
after release and therefore improve software reliability.

After deployment of the software product, field data can be gathered and
analyzed to study the behavior of software defects. Fault tolerance or
fault/failure forecasting techniques will be helpful techniques and guide rules
to minimize fault occurrence or impact of the fault on the system.

Relationship to other topics

Software Reliability is a part of software quality. It relates to many areas
where software quality is concerned.

Traditional/Hardware
Reliability

The initial quest in software reliability study is based on an analogy of
traditional and hardware reliability. Many of the concepts and analytical
methods that are used in traditional reliability can be used to assess and
improve software reliability too. However, software reliability focuses on
design perfection rather than manufacturing perfection, as traditional/hardware
reliability does.

Software Fault Tolerance

Software fault tolerance is a necessary part of a system with high
reliability. It is a way of handling unknown and unpredictable software (and
hardware) failures (faults) [Lyu95], by providing a
set of functionally equivalent software modules developed by diverse and
independent production teams. The assumption is the design diversity of
software, which itself is difficult to achieve.

Software Testing

Software testing serves as a way to measure and improve software
reliability. It plays an important role in the design, implementation,
validation and release phases. It is not a mature field. Advance in this field
will have great impact on software industry.

Social & Legal Concerns

As software permeates to every corner of our daily life, software related
problems and the quality of software products can cause serious problems, such
as the Therac-25 accident. The defects in software are significantly different
than those in hardware and other components of the system: they are usually
design defects, and a lot of them are related to problems in specification. The
unfeasibility of completely testing a software module complicates the problem
because bug-free software can not be guaranteed for a moderately complex piece
of software. No matter how hard we try, defect-free software product can not be
achieved. Losses caused by software defects causes more and more social and
legal concerns. Guaranteeing no known bugs is certainly not a good-enough
approach to the problem.

Conclusions

Software reliability is a key part in software quality. The study of
software reliability can be categorized into three parts: modeling, measurement
and improvement.

Software reliability modeling has matured to the point that meaningful
results can be obtained by applying suitable models to the problem. There are
many models exist, but no single model can capture a necessary amount of the
software characteristics. Assumptions and abstractions must be made to simplify
the problem. There is no single model that is universal to all the situations.

Software reliability measurement is naive. Measurement is far from
commonplace in software, as in other engineering field. "How good is the
software, quantitatively?" As simple as the question is, there is still no
good answer. Software reliability can not be directly measured, so other
related factors are measured to estimate software reliability and compare it
among products. Development process, faults and failures found are all factors
related to software reliability.

Software reliability improvement is hard. The difficulty of the problem
stems from insufficient understanding of software reliability and in general,
the characteristics of software. Until now there is no good way to conquer the
complexity problem of software. Complete testing of a moderately complex
software module is infeasible. Defect-free software product can not be assured.
Realistic constraints of time and budget severely limits the effort put into
software reliability improvement.

As more and more software is creeping into embedded systems, we must make
sure they don't embed disasters. If not considered carefully, software
reliability can be the reliability bottleneck of the whole system. Ensuring
software reliability is no easy task. As hard as the problem is, promising
progresses are still being made toward more reliable software. More standard
components, and better process are introduced in software engineering field.

Annotated References

[Lyu95] Michael R. Lyu,
Handbook of
Software Reliability Engineering. McGraw-Hill publishing, 1995, ISBN
0-07-039400-8.
HREF="http://portal.research.bell-labs.com/orgs/ssr/book/reliability/introduction.html">http://portal.research.bell-labs.com/orgs/ssr/book/reliability/introduction.html

This book gives a broad and in-depth overview of the Software Reliability
Engineering(SRE) research. It is comprehensive and up-to-date, embracing both
traditional mature modeling and prediction methods, and new emerging
techniques. Chapter one can be served as the introduction to Software
Engineering. The book contains 17 chapters, classified into three parts:
Technical Foundations, Practices and Experiences and Emerging Techniques. Part
one focuses on the traditional analysis, prediction, estimation, or simulation
approaches. Part two introduces case studies and best current practices of SRE.
Part three is devoted to summarizing newly deployed techniques in SRE such as
Software Reliability Simulation, Software Testing, Fault Tree Analysis and
Neural Networks. Page 567, etc.

The author is also active in many research projects listed in
HREF="http://www.cse.cuhk.edu.hk/~lyu/FYP.html">http://www.cse.cuhk.edu.hk/~lyu/FYP.html.

[RAC96] Reliability Analysis Center, Introduction to Software
Reliability: A state of the Art Review. Reliability Analysis Center (RAC),
1996. http://rome.iitri.com/RAC/

The RAC book has a broad range of short introductions to various Software
Reliability disciplines such as Software Reliability models, the contrast of
software issues to hardware, and various software engineering models and
metrics. It is very good to be used as an introduction and starting point to
arcane theories and abstract mathematics. It also has very thorough reference
lists.

[Rook90] Paul Rook, editor. Software Reliability Handbook. Centre for
Software Reliability, City University, London, U.K. 1990.

This book is another handbook on software reliability. Although not as new
as [Lyu95], it is also a good book.

[Keiller91] Keiller, Peter A. and Miller, Douglas R., "On the Use
and the Performance of Software Reliability Growth Models", Software
Reliability and Safety, Elsvier, 1991, (pp. 95-117)

[ANSI91] ANSI/IEEE, "Standard Glossary of Software Engineering
Terminology", STD-729-1991, ANSI/IEEE, 1991

Terminology standard. Has many standard definitions.

[Keene94] Keene, S. J., "Comparing Hardware and Software
Reliability", Reliability Review, 14(4), December 1994, pp. 5-7, 21

[IEEE95] IEEE, Charter and Organization of the Software Reliability
Engineering Committee, 1995

Gives the standard definition of Software Reliability Engineering, and
others.

[Sheffield] H. Lin, Scientific American, vol. 253, no. 6 (Dec. 1985),
p.48.

Sheffield hickups caused by software.

[Patriot] HREF="http://www.math.psu.edu/dna/455.f96/disasters.html">http://www.math.psu.edu/dna/455.f96/disasters.html

How patriot missile failed to intercept a scud in the gulf war.

[Telephone outage] HREF="http://www.byte.com/art/9512/sec6/art1.htm">http://www.byte.com/art/9512/sec6/art1.htm#aircontrol

A lot of items about failures caused by unreliable software. Horror story
38, telephone. An example of chaos caused by erroneous software upgrades.

[Neumann95] Neumann, P. Computer related risks. Addison Wesley, 1995.

The whole book summarizes many real events involving computer technologies
and the people who depend on those technologies, with widely ranging causes and
effects. In pp38, the defense system example can be found.

[Therac25]
HREF="http://ei.cs.vt.edu/~cs3604/lib/Therac_25/Therac_1.html">http://ei.cs.vt.edu/~cs3604/lib/Therac_25/Therac_1.html.
Nancy Leveson, Clark S. Turner, reprinted from "An Investigation of the
Therac-25 Accidents". IEEE Computer, Vol. 26, No. 7, July 1993, pp.
18-41.

The classical software-related fatalities and the classical paper.

[Ariane 5] Lions, J. (Chair), Ariane 5 Flight 501 Failure, European
Space Agency, Paris, July 19, 1996.
HREF="http://www.esrin.esa.it/htdocs/tidc/Press/Press96/ariane5rep.html">http://www.esrin.esa.it/htdocs/tidc/Press/Press96/ariane5rep.html.
(Accessed May 1, 1999)

A typical example of how a not properly handled exception can cause a failed
mission. Robustness can be expensive.

Software Reliability

Abstract:

Contents:

Introduction: Embedded Software -- Embedded
Disasters?

Key Concepts

Definition

Software failure mechanisms

The bathtub curve for Software Reliability

Available tools, techniques, and metrics

Relationship to other topics

Conclusions

Annotated References

Further Reading

Software Reliability

Abstract:

Contents:

Introduction: Embedded Software -- EmbeddedDisasters?

Key Concepts

Definition

Software failure mechanisms

The bathtub curve for Software Reliability

Available tools, techniques, and metrics

Relationship to other topics

Conclusions

Annotated References

Further Reading

Introduction: Embedded Software -- Embedded
Disasters?
